HPH-08
High Pressure Filters
Materials
Head: cast iron
Bowl: cold drawn steel
Max. working pressure：250 kg/cm²
HPH series have passed the pressure test by the Metal Industries Research & Development Centre.
Weight
HPH 08-1 : 4.48 kg
HPH 08-2 : 7.78 kg
| Model No. | A mm |
B mm |
C mm |
D mm |
*Weight kg |
|
| SE-HP-08 | Type 1 | 54 | 35 | 26 | 121 | 0.22 |
|---|---|---|---|---|---|---|
| Type 2 | 230 | 0.36 | ||||
*A10 μ glass fiber
