Spin-On Return Filters

Clean & Reliable Hydraulic Oil Protection



JUNWELL’s Spin-On Return Filters are made to clean hydraulic oil after system operation, ensuring only filtered fluid returns to the tank. As efficient Return filters, they help maintain system cleanliness, protect components, and extend equipment service life. The spin-on design allows quick and easy replacement, lessening maintenance time and downtime.



Manufactured in Taiwan with dependable quality and customizable options, these filters are suitable for a wide range of hydraulic applications, including engineering vehicles, agricultural machinery, marine systems, automotive equipment, and industrial machinery. They provide a practical and dependable solution for hydraulic system maintenance and protection.

RF-element

RF-element

Replace the element after the first 50 hours of operation, and every 250 hours thereafter.
The frequency of replacement depends on the operating conditions.

RF/RFT

RF/RFT

Working pressure：
RFT-06：100 PSI (6.8 bar max.)
RF-06/08：200 PSI (13.7 bar max. )
RF-10：100 PSI (6.8 bar max. )

Temprature (max.)：107 ºC (225 ºF)

Tank hole cutout is Ø65 mm for RFT-06 series.
